Carclo Optics 60148 TIR Optic

20 mm LED optics now available with wide 60° beam

Carclo Optics has introduced a new wide beam option to its range of 20 mm optics for LED light engines and luminaires.



The new 60148 total internal reflection (TIR) optic completes the line-up of 20 mm premium-quality optics from Carclo. Suitable for use in a range of applications, the 60148 features a 60° beam angle, and is a cost-effective and high-quality optical solution for LED luminaires.



Also new from Carclo, the 33Up baffle complements the 12927 33UP optic. It gives excellent results in numerous types of applications, including human-centric lighting, retail lighting and office lighting. The 33Up baffle is available in both black and white as a retrofit for the 12927 33Up optic. The baffle can also be purchased as a combined unit including the optic.

Part number

Product description

12927-WHT

Combination optic + white baffle

12927-BLK

Combination optic + black baffle

60147-WHT

White baffle only

60147-BLK

Black baffle only

Features

  • Low glare
  • Meets office lighting standards
  • Easy to assemble
  • Compatible with Philips Fortimo MidPower 3R HV4 Gen 4 board

Applications

  • Human-centric lighting
  • Retail lighting
  • Office lighting
