Infineon CFD7 Family of CoolMOS™ Superjunction MOSFETs

New 650V MOSFETs offer efficient operation in soft-switching topologies

Infineon has extended its CFD7 family of CoolMOS™ superjunction MOSFETs with new 650V-rated devices which offer high efficiency and power density in soft-switching industrial power supplies. The new parts offer an extra 50V of breakdown-voltage headroom over the existing range of 600V CFD7 MOSFETs.



The 650V CFD7 MOSFETs are notable for the fast integrated body diode, low reverse-recovery charge for improved switching performance, and excellent thermal behavior. The robust architecture makes the MOSFETs suitable for use in hard-commutation applications. The extra safety margin over 600V-rated MOSFETs is also helpful in designs which operate on a high bus voltage.



The CFD7 devices offer the best on-resistance ratings of any 650V MOSFET in a TO-247, TO-220, or D2PAK package. These ratings vary little over temperature.



The high light- and full-load efficiency and low power losses provided by the CFD7 MOSFETs in soft-switching topologies enable system designers to increase power density while maintaining high reliability in industrial applications which have a long operating lifetime.

Part Number

Package

Maximum On-resistance (mΩ)

Maximum Drain Current (A)

Gate Charge (nC)

IPW65R029CFD7

TO-247

29

69

145

IPZA65R029CFD7

Four-pin TO-247

29

69

145

IPP65R041CFD7

TO-220

41

50

102

IPB65R041CFD7

D2PAK (TO-263)

41

50

102

IPW65R041CFD7

TO-247

41

50

102

IPP65R060CFD7

TO-220

60

36

68

IPW65R060CFD7

TO-247

60

36

68

IPP65R090CFD7

TO-220

90

25

53

IPB65R090CFD7

D2PAK (TO-263)

90

25

53

IPW65R090CFD7

TO-247

90

25

53

IPB65R110CFD7

D2PAK (TO-263)

110

22

41

IPP65R110CFD7

TO-220

110

22

41

IPW65R110CFD7

TO-247

110

22

41

IPW65R125CFD7

TO-247

125

19

36

IPB65R125CFD7

D2PAK (TO-263)

125

19

36

IPB65R155CFD7

D2PAK (TO-263)

155

15

28

IPW65R155CFD7

TO-247

155

15

28

IPP65R155CFD7

TO-220

155

15

28

IPP65R190CFD7

TO-220

190

12

23

Features

  • 4V gate threshold voltage
  • 0V diode forward voltage
  • 70V/ns maximum reverse diode dv/dt
  • Thermal resistance: 0.98°C/W junction-to-case
  • Junction-temperature range: -55°C to 150°C

Applications

  • Telecoms equipment
  • Servers
  • Solar power generation
  • Off-board electric vehicle charging
