Maxim Integrated TMC2300 Two-Phase Driver for Stepper Motors

Driver IC produces silent stepper motor operation from a battery power supply

The TMC2300 from TRINAMIC Motion Control, now part of Maxim Integrated, is a two-phase driver for stepper motors, producing silent operation powered by a battery as small as two AA cells, or one or two lithium-ion cells.



Drawing on unique chopper and control technologies to achieve very high efficiency, the TMC2300 provides precise motor control, with up to 51,200 microsteps-per-revolution. The driver IC is housed in a compact QFN package which has a footprint of 3mm x 3mm.



The TMC2300 drives two-phase stepper motors operating at up to 1.2Arms and across an operating-voltage range of 1.8V to 11V DC. Very low power consumption, the result of the sophisticated StealthChop2™ chopper technology and the on-chip power switches’ very low on-resistance, means that the TMC2300 is ideal for use in IoT and handheld devices.



Maxim also supplies the TMC6300, a motor driver IC for Brushless DC (BLDC) motors, and the TMC7300, a dual DC motor driver IC.

Features

  • Integrated charge pump
  • <50nA stand-by current
  • Automatic stand-by current reduction
  • Single-wire UART and Step/Dir interface

Applications

  • Battery-powered equipment
  • Point-of-sale devices
  • Printers
  • Toys
  • Office automation equipment
  • Smart thermostatic radiator valves
  • Miniature medical devices

Reference Design Board

Board part number: TMC2300-IOT-REF



The TMC2300-IOT-REF is an open-source reference design for easy evaluation of the TMC2300-LA stepper motor driver IC running from a 3.5V-6V battery power supply.



The board includes the TMC2300 low-voltage stepper motor driver, a lithium-ion battery charger operating via a USB Type-C® connection, an ESP32-PICO-D4 processor with integrated Wi-Fi® and Bluetooth® Low Energy communications, as well as UART and USB Type-C interfaces for serial communication and programming.

Maxim Integrated - TMC2300-IOT-REF
