Manufacturer Part #
5747847-4
HD20 Series 37 Position Right Angle Socket Board Mount D-Sub Connector
|
|
|||||||||||
|
|
|||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: |
Product Variant Information section
Available PackagingPackage Qty:520 per Tray Mounting Method:Through Hole |
||||||||||
| Date Code: | 2534 | ||||||||||
Product Specification Section
TE Connectivity 5747847-4 - Product Specification
Shipping Information:
Item cannot ship to certain countries.
See List
Item cannot ship to following countries:
N/A
HTS Code:
N/A
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5747847-4&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-d-subs/5747847-4-te-connectivity-8564007
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5747847-4&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-d-subs/5747847-4-te-connectivity-8564007
TE Connectivity 5747847-4 - Technical Attributes
Attributes Table
| Style/Orientation: | Standard Board Mount Receptacle |
| No of Positions: | 37 |
| No of Rows: | 2 |
| Termination: | PCB |
| Pitch: | 2.76 mm |
| Material: | Front Metal |
| Shell Size: | 4 C |
| Gender: | Female |
| Color: | Black |
| Current Rating: | 6A |
| Contact Plating: | Gold |
| Insulation Resistance: | 5000MΩ |
| Operating Temperature: | -55°C to +105°C |
| Mounting Method: | Through Hole |
Features & Applications
The 5747847-4 is a part of HD20 Series 37 Position Right Angle Socket Board Mount D-Sub Connector.
Features:
- PCB Mounting Orientation = Right Angle
- Product Series = HD 20
- Mating Connector Lock = With
- Mating Connector Lock Type = Threaded Insert, 4-40 UNC
- PCB Mount Retention = With
- Shell Type = Front Metal Shell
- Shell Size = 4
- Boardlock Material = Copper Alloy
- Boardlock Plating = Tin
- Termination Post Length (mm [in]) = 3.18 [0.125]
- Solder Tail Contact Plating = Tin over Nickel
- Number of Positions = 37
- PCB Mount Retention Type = Boardlock(s)
- Shell Plating = Tin
- Eyelet Plating = Tin
- Contact Base Material = Phosphor Bronze
- Connector Style = Receptacle
Pricing Section
Global Stock:
1,040
USA:
1,040
Factory Lead Time:
10 Weeks
Quantity
Unit Price
5
$4.85
20
$4.75
40
$4.70
125
$4.61
250+
$4.52
Product Variant Information section
Available Packaging
Package Qty:
520 per Tray
Mounting Method:
Through Hole
