Vishay VSMA1094600 Infrared Emitter

IR emitters handle high continuous and pulse drive currents

The Vishay SurfLight™ portfolio includes multiple surface-mount infrared emitters with peak wavelengths of 940 nm or 850 nm.



The new Astral products feature a double-stack emitter chip to give very high radiant power. Operating at a continuous drive current of up to 1.5 A, the LEDs can also handle pulse currents of up to 5.0 A.



Part Number

Peak Wavelength

Angle of Half Intensity

Package Footprint

Package Height

VSMA1094600

940 nm

±60°

3.4 mm x 3.4 mm

1.8 mm

VSMA1094400

940 nm

±40°

3.4 mm x 3.4 mm

2.45 mm

VSMA1094250

940 nm

±28°

3.4 mm x 3.4 mm

2.9 mm

VSMA1085600

850 nm

±60°

3.4 mm x 3.4 mm

1.8 mm

VSMA1085400

850 nm

±40°

3.4 mm x 3.4 mm

2.45 mm

VSMA1085250

850 nm

±28°

3.4 mm x 3.4 mm

2.9 mm



Features

  • 1,425 mW radiant power at 1 A drive current
  • Low thermal resistance
  • Withstand up to 5 kV ESD according to ANSI/ESDA /JEDEC JS-001

Applications

  • Eye tracking
  • Safety and security systems
  • CCTV
