Renesas has introduced an application design framework which shows how an environment-aware, voice-activated lighting control system which complies with the requirements of the DALI-2 lighting interface standard can be implemented with components from Renesas, including parts from Dialog Semiconductor, which is now part of Renesas.
The CN252 framework is built around the Renesas RL78/I1A, a microcontroller which provides a rich set of functions for intelligent control of tunable white light outputs. It includes up to six channels of PWM control to give fine-tuned control of dimming and color.
The RL78/I1A capabilities take advantage of the DALI-2 interface, which enables network-based lighting control for building automation applications which are designed for compliance with IEC 62386 version 2 when used with suitable hardware. Compared to the original DALI specification, the DALI-2 standard provides for better control of brightness, glare, color rendering, and presence detection, as well as improved multi-vendor
Part Number | Functions |
OB1203 biosensor | Heart rate, blood oxygen concentration, pulse oximetry, proximity, light and color sensor |
iW380 LED driver | Second-stage 65 V buck LED driver with flicker-free true dc dimming technology for commercial lighting |
ISL80505 LDO | High-performance 500 mA LDO |
RL78/I1A MCU | Microcontroller which outputs high-resolution PWM for fine dimming and toning of LED lighting |
RA4M2 MCU | 100 MHz Arm® Cortex®-M33-based microcontroller with TrustZone® security technology |
PS2561F-1 photocoupler | DIP photocoupler operating at ambient temperatures up to 110°C |
PS2911-1 photocoupler | 4-pin flat-lead photocoupler in an ultra-small package. High current transfer ratio. |
ISL29501 proximity sensor | Time-of-flight signal processing IC |
iW3627 PWM controller | Digital constant-voltage offline PWM controller with PFC for applications up to 90 W |
