TE Connectivity — LUMAWISE Endurance N+ Base and Cover

TE Connectivity (TE) supplies the LUMAWISE Endurance N+ ANSI C136-compliant

base assembly with integral seal gasket. The assembly includes a clear, translucent cover which fits on the black base.

The base assembly provides a power and signal interface between the network lighting control cabling and a luminaire-mounted receptacle. The base assembly provides an IP66-rated control enclosure which protects the wiring from harsh outdoor conditions, including rain, snow, and salt spray.

The translucent cover allows the transmission of daylight to a light sensing device in the base. A vent in the base assembly helps to keep electronics devices inside the enclosure dry, extending their lifetime.

The Endurance N+ base assembly is supplied in 3-, 5-, and 7-position versions:

• The 3-position version has three power contacts
• The 5-position version has three power contacts and two dimming/signal contacts
• The 7-position version has three power contacts and four dimming/signal contacts
