Kingbright

Surface-mount bi-color LEDs have very small board footprint

Kingbright products give system designers a choice of color combinations

Kingbright supplies a range of surface-mount bi-color LEDs which are ideal for use in space-constrained board designs. The LEDs are available in red/green, red/yellow and yellow/green color combinations.



The LEDs are housed in an 0202 package which has a 0.65 mm x 0.65 mm footprint and is just 0.2 mm high.



Kingbright uses advanced semiconductor technology to maximize luminous intensity while maintaining low power consumption. The LED emitters are made with AlGaInP material on a GaAs substrate.



Part Number

Colors

Dominant Wavelengths

Luminous Intensity at
5 mA Drive Current

APGF0606SEEKCGKCTTC2

Red/green

624 nm/571 nm

Red: 80 mcd

Green: 8 mcd

APGF0606SEEKCGKXC-TT

Red/green

624 nm/571 nm

Red: 80 mcd

Green: 8 mcd

APGF0606SEEKSYKXC-TT

Red/yellow

624 nm/589 nm

Red: 80 mcd

Yellow: 17 mcd

APGF0606SYKCGK-TT-C2

Yellow/green

589 nm/571 nm

Yellow: 17 mcd

Green: 8 mcd

Features

  • 140° viewing angle
  • Water-clear lens
  • 10 mA maximum drive current
  • 3 V maximum forward voltage
  • 3 kV ESD capability on the human-body model
  • Operating-temperature range: -40°C to 85°C

Applications

  • Backlights
  • Status indicators
  • Home appliances
  • Wearable devices
  • Portable devices
  • Healthcare equipment
