Manufacturer Part #
5-103957-1
AMPMODU 2 Position 2.54 mm Pitch Single Row IDC Receptacle Housing
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:2310 per Tube | ||||||||||
| Date Code: | |||||||||||
Product Specification Section
TE Connectivity 5-103957-1 - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5-103957-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-pcb--socket-plug-wire-mount/5-103957-1-te-connectivity-4706826
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5-103957-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-pcb--socket-plug-wire-mount/5-103957-1-te-connectivity-4706826
TE Connectivity 5-103957-1 - Technical Attributes
Attributes Table
| Type: | Wire to Board |
| No of Positions: | 2 |
| Pitch: | 2.54 mm |
| Style/Orientation: | Free Hanging Socket/Receptacle |
| Termination: | IDC |
Features & Applications
The 5-103957-1 is a AMPMODU 2 position single row 2.54 mm pitch preloaded IDC Receptacle Housing. It has an operating temperature ranging from - 65°C to 105°C.
Features:
- Product Type Features:
- Product Type = Connector
- Connector Type = Housing
- Termination Method to Wire/Cable = Crimp, Insulation Displacement Crimp (IDC)
- Wire Insulation Diameter (mm [in]) = 1.37 [0.054]
- Connector Series = MTE
- Applied Pressure = Standard
- Electrical Characteristics:
- Contact - Rated Current (A) = 3
- Termination Resistance (m?) = 15
- Insulation Resistance (M?) = 5,000
- Dielectric Withstanding Voltage (V) = 600
- Termination Features:
- Solder Tail Contact Plating = Tin
- Body Features:
- Centerline (mm [in]) = 2.54 [0.100]
- Row-to-Row Spacing (mm [in]) = 2.54 [0.100]
- Number of Positions = 2
- Number of Rows = 1
- Wire Range (mm [AWG]) = 0.12-0.40² [26-22]
- Contact Features:
- Contact Type = Socket
- Contact Plating, Mating Area, Material = Gold (15)
- Contact Base Material = Phosphor Bronze
- Housing Features:
- Connector Style = Receptacle
- Mating Alignment Type = Latched
- Housing Color = Black
- UL Flammability Rating = UL 94V-0
- Housing Material = Thermoplastic - GF
View the available family of AMPMODU IDC receptacle
Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Lead Time:
17 Weeks
Quantity
Unit Price
2,310+
$0.40
Product Variant Information section
Available Packaging
Package Qty:
2310 per Tube
