CAP1188-1-CP-TR
EIGHT CHANNEL CAPACITIVE TOUCH SENSOR WITH 8 LED DRIVE
| | |||||||||||
| | |||||||||||
| Mfr. Name: | Microchip | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:5000 per Reel Package Style:QFN-24EP Mounting Method:Surface Mount | ||||||||||
| Date Code: | |||||||||||
Microchip CAP1188-1-CP-TR - Product Specification
Shipping Information:
ECCN:
PCN Information:
Revision History:May 5, 2021: Issued initial notification.May 11, 2021: Re-issued initial notification. Corrected the attached Qualification Plan and Pre and Post Change Summary.October 28, 2021: Issued final notification. Updated estimated qualification completion date to be on January 2022.November 15, 2021: Re-issued final notification. Updated the notification subject, description of change and affected CPN list to include the USX2030 device family. Updated the time table summary. Attached the qualification report. Provided estimated first ship date to be on November 26, 2021.Description of Change:Qualification of STA as an additional assembly site for selected CAP1188, USB33xx and USX2030 device families available in 24L VQFN (4x4x0.9mm) package.Pre and Post Change Summary: see attachedImpacts to Data Sheet:NoneChange Impact: NoneReason for Change:To improve manufacturability by qualifying STA as an additional assembly site.Change Implementation Status:In ProgressEstimated First Ship Date: November 26, 2021 (date code: 2148)NOTE: Please be advised that after the estimated first ship date customers may receive pre and post change parts
PCN Status:Final NotificationPCN Type:Manufacturing ChangeDescription of Change:Qualification of STA as an additional assembly site for selected CAP1188 and USB33xx device families available in 24L VQFN (4x4x0.9mm) package.Impacts to Data Sheet:NoneChange ImpactNoneReason for Change:To improve manufacturability by qualifying STA as an additional assembly site.Change Implementation Status:In ProgressEstimated Qualification Completion Date:January 2022
Revision History:May 5, 2021: Issued initial notification.May 11, 2021: Re-issued initial notification. Corrected the attached Qualification. Plan and Pre and Post Change Summary.Description of Change:Qualification of STA as an additional assembly site for selected CAP1188 and USB33xx device families available in 24L VQFN (4x4x0.9mm) package.Pre and Post Change Summary:See attachedReason for Change:To improve manufacturability by qualifying STA as an additional assembly siteChange Implementation Status: In ProgressEstimated Qualification Completion Date:September 2021Note: Please be advised the qualification completion times may be extended because of unforeseen business conditions however implementation will not occur until after qualification has completed and a final PCN has been issued. The final PCN will include the qualification report and estimated first ship date. Also note that after the estimated first ship date guided in the final PCN customers may receive pre and post change parts.
PCN Status: Initial notification.PCN Type: Manufacturing Change Description of Change: Qualification of STA as an additional assembly site for selected CAP1188 and USB33xx device families available in 24L VQFN (4x4x0.9mm) package Impacts to Data Sheet: NoneChange Impact: NoneReason for Change: To improve manufacturability by qualifying STA as an additional assembly siteChange Implementation Status: In ProgressEstimated Qualification Completion Date: September 2021
Data Sheet - CAP1188 8 Channel Capacitive Touch Sensor with 8 LED Drivers Data Sheet Document RevisionDescription of Change: 1) Features, Table 2-1, "Pin Description for CAP1188", Table 2-2, "Pin Types", Section 5.0, "General Description": References to BC-Link Interface, BC_DATA, BC_CLK, BC-IRQ#, BC-Link bus have been removed. 2) Application Note under table 2-6: [BC-Link] hidden in data sheet. 3) Table 3-2, "Electrical Specifications": BC-Link Timing Section hidden in data sheet. 4) Section 4.1: Modified paragraph under section 4.1. 5) Table 4-1: Protocol Used for 68K Pull Down Resistor changed from "BC-Link Communications" to "Reserved". 6) Section 4.1.3 BC-Link Communications: Removed this section and Application Note. 7) Section 4.2.2, "SMBus Address and RD / WR Bit": Replaced "client address" with "slave address" in this section. 8) Section 4.2.4, SMBus ACK and NACK Bits, Section 4.2.5, SMBus Stop Bit, Section 4.2.7, SMBus and I2C Compatibility: Replaced "client" with "slave" in these sections. 9) Table 4-4, "Read Byte Protocol": Heading changed from "Client Address" to "Slave Address". 10) Section 5.1, Power States: Removed "BC-Link" Application Notes. 11) Table 6-1: Register Name for Register Address 77h changed from "LED Linked Transition Control" to "Linked LED transistion Control". 12) Section 6.1 Main Control Register: BC-Link paragraph removed from Bit 4 under Table 6-3. 13) Section 6.30: changed CS8 to LED8. 14) table 6-53: Modified B3 bit name. 15) Section 7.7 Package Marking: Updated package drawing. 16) Appendix A: Device Delta: changed 2Dh to 2Fh in item #12. 17) Product Identification System: Removed BC-Link references.
Part Status:
Microchip CAP1188-1-CP-TR - Technical Attributes
| Type: | Capacitive |
| Output Type: | Digital |
| Supply Voltage: | 3V to 3.6V |
| Supply Current: | 120µA |
| Package Style: | QFN-24EP |
| Mounting Method: | Surface Mount |
Available Packaging
Package Qty:
5000 per Reel
Package Style:
QFN-24EP
Mounting Method:
Surface Mount
