Infineon EVAL IMD700A FOC 3SH Evaluation Board

OptiMOS™ low-voltage power MOSFET 40V in PQFN 3.3x3.3 Source-Down package with industry leading RDS(on)

Infineon is extending the innovative Source-Down family with the IQE013N04LM6 1.35 mΩ, 40 V in a 3.3x3.3 PQFN package (also available in a Center-Gate version). This new best-in-class power MOSFET challenges the status quo in power density and form factor in end applications. Optimizing user experience in power tools, one design target is to minimize internal restriction on the PCB area to enable more ergonomic tool design. Moving the inverter from the handle into the head minimizes the volume of the motor housing. Torque can be kept at a reasonably high level to enable quick and easy action. With the design goal to achieve the smallest possible form factor of the motor drive circuit, a MOSFET case temperature of ~100°C is acceptable under the full load. Utilizing the performance advantages of the new IQE013N04LM6, a maximum power of 400 W can be achieved with optimized form factor while staying within the defined limits.

MOTIX™ fully programmable motor controller combining microcontroller and gate driver IC

The MOTIX™ IMD701A is Infineon’s fully programmable motor controller integrating XMC1404 microcontroller with 6EDL7141 3-phase gate driver IC in one package to enable the development of next generation battery operated products using BLDC or PMSM motors. With integrated precision power supply and current shunt amplifiers, many of the peripheral circuitry is no longer necessary allowing reduction in PCB space and improved system packaging possibilities.
