Manufacturer Part #
AZ952-1CM-5DSE
AZ952 Series SPDT 1 Form C 5VDC Power Relay
| | |||||||||||
| | |||||||||||
| Mfr. Name: | American Zettler | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:100 per Box Mounting Method:Through Hole | ||||||||||
| Date Code: | 2322 | ||||||||||
Product Specification Section
American Zettler AZ952-1CM-5DSE - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=AZ952-1CM-5DSE&field4=American Zettler&field18=https://p1na.futureelectronics.com/p/2081962
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=AZ952-1CM-5DSE&field4=American Zettler&field18=https://p1na.futureelectronics.com/p/2081962
American Zettler AZ952-1CM-5DSE - Technical Attributes
Attributes Table
| Relay Type: | General Purpose |
| Coil Type: | Non-Latching |
| Contact Form: | SPDT (1 Form C) |
| Coil Current: | 41.7mA |
| Nominal Coil Voltage: | 5V |
| Contact Current-Max: | 3A |
| Coil Resistance: | 120Ω |
| Switching Voltage: | 60V |
| Contact Material: | Silver (Ag), Gold (Au) |
| Operating Temp Range: | -25°C to +75°C |
| Termination Style: | PC Pin |
| Mounting Method: | Through Hole |
Pricing Section
Global Stock:
1,500
USA:
1,500
On Order:
0
Factory Lead Time:
N/A
Quantity
Unit Price
100
$0.495
200
$0.485
400
$0.475
1,500+
$0.46
Product Variant Information section
Available Packaging
Package Qty:
100 per Box
Mounting Method:
Through Hole
