Manufacturer Part #

1-794617-4

MATE-N-LOK 14 Position Dual Row 3 mm Pitch Receptacle Housing connector

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Date Code: 2103
Product Specification Section
Technical Attributes
Attributes Table
Type: Housing
No of Positions: 14
Pitch: 3 mm
Style/Orientation: Receptacle
Termination: Crimp
Features & Applications

The 1-794617-4 is a Part of MATE-N-LOK Series with 14 Position Dual Row 3 mm Pitch Receptacle Housing connector.

Micro MATE-N-LOK 3mm Connector System is a wire-to-wire and wire-to-board connector system.

Features:

  • Product Type = Connector
  • Connector Type = Housing
  • Mount = Free Hanging
  • Mating Retention Type = Latching
  • Voltage (VAC) = 250
  • Row-to-Row Spacing in mm = 3.00
  • Current Rating (A) = 5
  • Contact Type = Socket
  • Contact Layout = Double-Row
  • Connector Style = Receptacle
  • Housing Material = Nylon
  • Housing Color = Black

Mating Products:

  • 1-794615-4
  • 1-794616-4
  • 1-794630-4
  • 1-794631-4

Applications:

  • Appliance
  • Instrumentation
  • Industrial machinery
  • Home equipment
  • Security system industries

View the MATE-N-LOK Series of Connectors

Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Stock:Factory Stock:
8,308
Factory Lead Time:
19 Weeks
Minimum Order:
800
Multiple Of:
800
tariff icon
Tariff charges may apply if shipping to the United States. An estimate of tariff charges will be calculated at checkout.
Total
$460.00
USD
Quantity
Web Price
1
$0.695
50
$0.61
150
$0.59
300
$0.575
1,000+
$0.555
