Manufacturer Part #
ST1S03PUR
ST1S03 Series 16 V 1.5 MHz Surface Mount Step-Down Switching Regulator - DFN-8
| | |||||||||||
| | |||||||||||
| Mfr. Name: | STMicroelectronics | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:3000 per Reel Package Style:DFN-6D Mounting Method:Surface Mount | ||||||||||
| Date Code: | |||||||||||
Product Specification Section
STMicroelectronics ST1S03PUR - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=Asia&field16=en&field2=ST1S03PUR&field4=STMicroelectronics&field18=https://p1apac.futureelectronics.com/es/p/semiconductors--analog--regulators-reference--switching-regulators/st1s03pur-stmicroelectronics-4023051
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=Asia&field16=en&field2=ST1S03PUR&field4=STMicroelectronics&field18=https://p1apac.futureelectronics.com/es/p/semiconductors--analog--regulators-reference--switching-regulators/st1s03pur-stmicroelectronics-4023051
STMicroelectronics ST1S03PUR - Technical Attributes
Attributes Table
| Topology: | Buck |
| Input Voltage: | 16V |
| Output Current-Max: | 1.5A |
| Output Type: | Adjustable |
| Switching Frequency-Max: | 1.8MHz |
| Operating Temp Range: | 150°C |
| Duty Cycle-Max: | 87% |
| Efficiency: | 70% |
| No. of Outputs: | 1 |
| Quiescent Current: | 2.5mA |
| Storage Temperature Range: | -25°C to +150°C |
| Load Regulation (%): | 0.003% |
| Package Style: | DFN-6D |
| Mounting Method: | Surface Mount |
Pricing Section
Global Stock:
0
Singapore:
0
Factory Lead Time:
24 Weeks
Quantity
Unit Price
3,000+
$0.61
Product Variant Information section
Available Packaging
Package Qty:
3000 per Reel
Package Style:
DFN-6D
Mounting Method:
Surface Mount
