Manufacturer Part #
208130-1
CPC Series 1 Panel Mount Receptacle 4 Position Circular Plastic Connector
|
|
|||||||||||
|
|
|||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: |
Product Variant Information section
Available PackagingPackage Qty:600 per Bag |
||||||||||
| Date Code: | |||||||||||
TE Connectivity 208130-1 - Product Specification
Shipping Information:
HTS Code:
ECCN:
PCN Information:
Product Description: CPC HousingsKind of change:MaterialGeneral Description of ChangesThe CPC portfolio is undergoing material harmonization to a consolidated Polybutylene Terephthalate (PBT) resin, including the transition of Nylon (PA) components and the incorporation of all applicable parts into the updated material framework. The new PBT material meets all current functional and performance requirements of the component and is fully qualified for the intended application.Reason for Changes:TE are transitioning and consolidating to a new resin material (PBT) as part of our commitment to sustainability and improved service. This material change enables a reduction of approximately 30% in CO emissions and enhances supply chain reliability. It also supports better alignment across our product lines, helping us respond more consistently to customer needs and maintain a high level of service.First Ship Date of Changed Items (Changed Parts Only): 15-JUL-2026
Part Status:
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=208130-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-circular/208130-1-te-connectivity-7802879
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=208130-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-circular/208130-1-te-connectivity-7802879
TE Connectivity 208130-1 - Technical Attributes
| Type: | CPC-Connector |
| Style/Orientation: | Panel Mount Receptacle |
| No of Positions: | 4 |
| Mating Type: | Threaded |
| Termination: | Male/Pin Crimp |
| Material: | Plastic |
| Shell Size: | 11 |
| Operating Temp Range: | -55°C to +105°C |
Features & Applications
The 208130-1 is a panel mount receptacle 4 position circular plastic connector
Features:
- Connector Type = Housing
- Mount = Panel
- Mount Angle = Straight
- Shell Size = 11
- Number of Power Positions = 0
- Mating Retention Type = Threaded Coupling
- mber of Positions = 4
- Number of Signal Positions = 4
- Contact Type = Pin
- Reverse Gender = Standard
- Connector Style = Receptacle
- Mating Alignment Type = Keyed
- Housing Material = Thermoplastic - GF
- RoHS/ELV Compliance = RoHS compliant, ELV compliant
Available Packaging
Package Qty:
600 per Bag
