Manufacturer Part #
5788792-1
HD20 Series 9 Position Right Angle Plug Board Mount D-Sub Connector
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:130 per Tray Mounting Method:Through Hole | ||||||||||
| Date Code: | 2414 | ||||||||||
Product Specification Section
TE Connectivity 5788792-1 - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5788792-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-d-subs/5788792-1-te-connectivity-8554479
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=5788792-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-d-subs/5788792-1-te-connectivity-8554479
TE Connectivity 5788792-1 - Technical Attributes
Attributes Table
| Style/Orientation: | Standard Board Mount Plug |
| No of Positions: | 9 |
| No of Rows: | 2 |
| Termination: | PCB |
| Pitch: | 2.28 mm |
| Material: | Front Metal |
| Shell Size: | 1 E |
| Gender: | Male |
| Color: | Black |
| Current Rating: | 6A |
| Voltage Rating: | 125V |
| Contact Plating: | Gold |
| Insulation Resistance: | 5000MΩ |
| Operating Temperature: | -55°C to +105°C |
| Mounting Method: | Through Hole |
Features & Applications
The 5787683-1 is a HD-20 Series 15 Position Receptacle Standard Board Mount D-Sub Connector.
Features:
- PCB Mounting Orientation = Right Angle
- Product Series = HD 20
- Mating Connector Lock = With
- PCB Mount Retention = With
- Shell Type = Front Metal Shell
- Shell Size = 1
- Panel Mount Retention = Without
- Grounding Clips = Without
- Termination Post Length (mm [in]) = 3.18 [0.125]
- Solder Tail Contact Plating = Tin over Nickel
- Number of Positions = 9
- Contact Base Material = Copper Alloy
- Connector Style = Plug
- UL Flammability Rating = UL 94V-0
- Housing Material = Thermoplastic - GF
- RoHS/ELV Compliance = RoHS compliant, ELV compliant
Pricing Section
Global Stock:
395
USA:
395
On Order:
0
Factory Lead Time:
25 Weeks
Quantity
Unit Price
130
$2.13
260
$2.11
390
$2.10
520
$2.09
650+
$2.06
Product Variant Information section
Available Packaging
Package Qty:
130 per Tray
Mounting Method:
Through Hole
