Manufacturer Part #
PIC32MZ2048ECG144-I/PL
PIC32MZ Series 2 MB Flash 512 kB SRAM SMT 32-Bit Microcontroller - LQFP-144
| | |||||||||||
| Mfr. Name: | Microchip | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:60 per Tray Package Style:LQFP-144 Mounting Method:Surface Mount | ||||||||||
| Date Code: | |||||||||||
Product Specification
Shipping Information:
ECCN:
PCN Information:
PCN Status: Initial notificationPCN Type: Manufacturing ChangeDescription of Change: Qualification of G631HQ mold compound material for selected products available in 144L LQFP (20x20x1.4mm) package at ANAP assembly site.Pre Change: Using G700L molding compound Post Change:Using G631HQ molding compoundImpacts to Data Sheet: NoneChange Impact: None Reason for Change: To improve manufacturability by qualifying G631HQ molding compound materialChange Implementation Status: In Progress Estimated Qualification Completion Date:January 2021
ERRATA - PIC32MZ Graphics (DA) Family Silicon ErrataMicrochip has released a new DeviceDoc for the PIC32MZ Graphics (DA) Family Silicon Errata of devicesDescription of Change: 1) Added Silicon Issues 53. (EBI), 54. (I2C), 55. (I2C), 56. (Input Capture), 57. (SDHC), 58. (Sleep), 59. (SPI), 60. (SQI), 61. (Timer2-9), 62. (Timer2-9), 63. (Timer2-9), 64. (USB), 65. (USB), and 66. (USB). 2) Removed previous Data Sheet Clarifications for Module 1 ComparatorReason for Change: To Improve ManufacturabilityPlease be advised that this is a change to the document only the product has not been changed.
Description of Change:1) Added Silicon Issue 32. Module:Reset.2) Added Data Sheet Clarifications: 1. Module:Pinout Updates, 2. Module:DC16 VPOR Specification, and 33. Module:I2C3.3) Updated Silicon Issue 2 on Module:Oscillator. Reason for Change: To Improve ProductivityDate Document Changes Effective: 04 Mar 2019NOTE: Please be advised that this is a change to the document only the product has not been changed.
Microchip has released a new DeviceDoc for the PIC32MZ Embedded Connectivity (EC) Family Silicon Errata and Data Sheet of devices.Description of Changes: 1) Removed data sheet clarification 1 (System Bus Arbitration). 2) Added silicon issues 63 (Resets), 64 (Crypto Engine) and 65 (Crypto Engine) 3) Added data sheet clarifications 2 (Program Flash Memory Wait States) and 3 (System Timing Requirements).Reason for Change: To Improve ProductivityDate Document Changes Effective: 21 Jan 2018NOTE: Please be advised that this is a change to the document only the product has not been changed.
Product Lifecycle:
Technical Attributes
| Family Name: | PIC32MZ |
| Core Processor: | MIPS32 microAptiv |
| Program Memory Type: | Flash |
| Flash Size (Bytes): | 2MB |
| RAM Size: | 512kB |
| Speed: | 200MHz |
| No of I/O Lines: | 120 |
| InterfaceType / Connectivity: | EBI/EMI/Ethernet/I2C/SPI/SQI/UART/USART/USB OTG |
| Peripherals: | Brown-out Detect/DMA/I2S/POR/PWM/Reset/Watchdog |
| Number Of Timers: | 9 |
| Supply Voltage: | 2.3V to 3.6V |
| Operating Temperature: | -40°C to +85°C |
| On-Chip ADC: | 48-chx12-bit |
| Watchdog Timers: | 1 |
| Package Style: | LQFP-144 |
| Mounting Method: | Surface Mount |
Available Packaging
Package Qty:
60 per Tray
Package Style:
LQFP-144
Mounting Method:
Surface Mount
