  6. ZTX689BSTZ

Diodes Incorporated | ZTX689BSTZ

Manufacturer Part #

ZTX689BSTZ

ZTX689B Series NPN 2 A 20 V Silicon Planar Medium Power Transistor - TO-92-3

ECAD Model:
Mfr. Name: Diodes Incorporated
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
Diodes Incorporated ZTX689BSTZ - Technical Attributes
Attributes Table
Polarity: NPN
CE Voltage-Max: 20V
Collector Current Max: 2A
Power Dissipation-Tot: 1.5W
Package Style:  TO-92
Mounting Method: Through Hole
Features & Applications

The ZTX689BSTZ is a NPN Silicon planar medium power high gain transistor with Low saturation voltage and 20 V collector to Emitter voltage.

Features:

  • 20 Volt VCEO
  • Gain of 400 at IC=2 Amps
  • Very Low saturation voltage

Applications:

  • Darlington replacement
  • Flash gun convertors
  • Battery powered circuits
  • Motor drivers
