Image for illustration purposes only,
refer to technical specifications

Manufacturer Part #

NMV0515SAC

NMV Series 1 W Single Output 15 V Isolated Through Hole DC/DC Converter

NMV0515SAC Datasheet
ECAD Model: Convert this file for your ECAD tool by downloading the free Library Loader. Learn more about ECAD model.
Mfr. Name:	Murata Power Solutions
Standard Pkg:	Product Variant Information section Available Packaging Package Qty: 25 per Tube Mounting Method: Through Hole
Date Code:

Murata Power Solutions NMV0515SAC - Technical Attributes

Type:	Encapsulated
Isolation:	Isolated
No of Outputs:	Single
Output Power:	1W
Output Voltage:	15V
Input Voltage:	5V
Mounting Method:	Through Hole

Features & Applications

The NMV0515SAC is a part of NMV series industrial temperature range DC/DC converters are the standard buliding blocks for on-board distributed power systems. They are ideally suited for providing local supplies on control system boards with the added benefit of 3 kV DC galvanic isolation to reduce switching noise.

Available in SIP and DIP with dual and single output pinout. All of the rated power may be drawn from a single pin provided the total load does not exceed 1 watt.

Features:

RoHS compliant
Efficiency to 79%
Power density up to 0.85 W/cm3
Wide temperature performance at full 1 Watt load, –40°C to 85°C
Single or dual output
UL 94V-0 package material
No heatsink required
Footprint from 1.17cm2
Industry standard pinout
Power sharing on dual output
3 kVDC isolation (1 minute)
5 V, 12 V, & 15 V input
5 V, 9 V, 12 V and 15 V output
Internal SMD construction
Fully encapsulated with toroidal magnetics
No external components required
MTTF up to 4.2 million hours
