Manufacturer Part #
AEV14012W
AEV Series 12V 120A SPST-NO Chassis Mount High capacity Cut-off Automotive Relay
| | |||||||||||
| | |||||||||||
| Mfr. Name: | Panasonic Industry | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:1 per Box Mounting Method:Chassis Mount | ||||||||||
| Date Code: | |||||||||||
Panasonic Industry AEV14012W - Product Specification
Shipping Information:
ECCN:
PCN Information:
Description:The Panasonic Industry part numbers are being marked as Not Recommended for New Designs (NRFND). As these products are older and demand has steadily declined with no anticipated future growth, we recognize that this change may cause some inconvenience. If recommended alternatives are available, please refer to the attached documents or contact us directly. Panasonic appreciate your business and look forward to continuing to support your needs.Effective Date: 10/01/2025
Part Status:
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=AEV14012W&field4=Panasonic Industry&field18=https://p1na.futureelectronics.com/p/electromechanical--relays--automotive-relays/aev14012w-panasonic-industry-3132247
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=AEV14012W&field4=Panasonic Industry&field18=https://p1na.futureelectronics.com/p/electromechanical--relays--automotive-relays/aev14012w-panasonic-industry-3132247
Panasonic Industry AEV14012W - Technical Attributes
| Relay Type: | Automotive |
| Contact Form: | SPST (1 Form A) |
| Contact Current-Max: | 120A |
| Nominal Coil Voltage: | 12V |
| Termination Style: | Stud |
| Coil Type: | Non-Latching |
| Coil Current: | 353mA |
| Coil Resistance: | 34Ω |
| Switching Voltage: | 400V |
| Power Dissipation: | 4.2W |
| Contact Material: | Molybdenum |
| Insulation Resistance: | 100mΩ |
| Operating Temp Range: | -40°C to +80°C |
| Mounting Method: | Chassis Mount |
Available Packaging
Package Qty:
1 per Box
Mounting Method:
Chassis Mount
