Manufacturer Part #
776495-1
DEUTSCH AMPSEAL 8 Position Locking Ramp Straight Receptacle Housing Male Pin
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:1 per Box | ||||||||||
| Date Code: | 2427 | ||||||||||
TE Connectivity 776495-1 - Product Specification
Shipping Information:
ECCN:
PCN Information:
Description of Changes: Manufacturing location changeThe TE approved supplier for the AMPSEAL 16 wire (mat) seals currently molds those seals in the United States. This same supplier also molds the peripheral seals as well but at their China manufacturing facility where the mold was built. The supplier is planning to move the wire seal molds to their China manufacturing facility. The supplier built the wire seal molds in the US with ultimate plans to move the tooling to China where their primary manufacturing facility is located. By having the wire seal tools and the peripheral seal tools at the same manufacturing facility, stricter process and quality controls will become more efficient.
Description of Changes:Manufacturing location changeThe TE approved supplier for the AMPSEAL 16 wire (mat) seals currently molds those seals in the United States. This same supplier also molds the peripheral seals as well but at their China manufacturing facility where the mold was built. The supplier is planning to move the wire seal molds to their China manufacturing facility. The supplier built the wire seal molds in the US with ultimate plans to move the tooling to China where their primary manufacturing facility is located. By having the wire seal tools and the peripheral seal tools at the same manufacturing facility, stricter process and quality controls will become more efficient.
Part Status:
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=776495-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connector-tools-contacts-accessories/776495-1-te-connectivity-7448335
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=776495-1&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connector-tools-contacts-accessories/776495-1-te-connectivity-7448335
Features & Applications
The 776495-1 is a AMPSEAL Latch Lock Straight Receptacle Housing Male Pin Connector with 8 Position and 4.5 mm Pitch.
Features:
- Product Line = AMPSEAL 16
- Product Type = Connector
- Connector Type = Housing
- Wire/Cable Type = Discrete Wire
- Contact Retention Type = Terminal Position Assurance (TPA)
- Mating Retention Type = Latching
- Contact - Rated Current (A) = 13
- Operating Voltage (VDC) = 250
- Wire Type = Stranded
- Cable Exit Angle = Straight
- Row-to-Row Spacing (mm [in]) = 5.30 [0.209]
- Connector Style = Receptacle
- Centerline (mm [in]) = 4.50 [0.177]
- Housing Color = Black
- Number of Positions = 8
- Number of Rows = 2
- Operating Temperature (°C [°F]) = -40 – +125 [-40 – +257]
- Applies To = Wire/Cable
- Contact Type = Pin
- Contact Layout = In-Line
- Application Use = Wire-to-Wire
- Contact Transmits (Typical Application) = Signal (Data)/Power
Available Packaging
Package Qty:
1 per Box
