TE Connectivity | 5747193-2

Manufacturer Part #

5747193-2

HD20 Series 50 Position Right Angle Receptacle Board Mount D-Sub

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Product Variant Information section
Date Code: 2518
Product Specification Section
TE Connectivity 5747193-2 - Technical Attributes
Attributes Table
Style/Orientation: Standard Board Mount Receptacle
No of Positions: 50
No of Rows: 3
Termination: Straight Solder Pins
Pitch: 2.76 mm
Material: Full Metal
Shell Size: 5 D
Gender: Female
Color: Black
Current Rating: 6A
Voltage Rating: 125V
Contact Plating: Gold
Insulation Resistance: 5000MΩ
Operating Temperature: -55°C to +105°C
Mounting Method: Through Hole
Features & Applications

The 5747193-2 is a 50 Position Female Front metal right angle AMPLIMITE D-Sub Connectors.

Product Highlights:

  • 50 Positions
  • Connector Style = Receptacle
  • PCB Mounting Orientation = Right angle
  • Product Series = HD 20
  • With Mating Connector Lock
  • Sealed = No
  • Profile = High
  • Post Size (mm [in]) = 0.64 [.025]
  • Mounting Hole Diameter (mm [in]) = 3.05 [.120]
  • Shell Material = Steel
  • UL Flammability Rating = UL 94V-0
  • Housing Material = Thermoplastic - GF

Applications:

  • Industrial
  • Automotive





Pricing Section
Global Stock:
477
USA:
477
On Order:
0
Factory Stock:Factory Stock:
0
Factory Lead Time:
31 Weeks
Minimum Order:
7
Multiple Of:
7
tariff icon
Tariff charges may apply if shipping to the United States. An estimate of tariff charges will be calculated at checkout.
Total
$165.27
USD
Quantity
Unit Price
7
$23.61
14
$23.44
28
$23.28
35
$23.23
105+
$22.92
