Manufacturer Part #

5555248-1

8 Position Single Port Right Angle Through Hole RJ45 Modular Jack

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
Technical Attributes
Attributes Table
Style: Standard Jack
No of Positions: 8
Mounting Method: Surface Mount
Features & Applications

The 5555248-1 is a Cable Mounted Modular Jack with high performance and stacked the Stacked Modular Jacks with low profile and narrow width allow more ports to be packed into less space.

Product Features:

  • Product Type = Connector
  • Jack Type = RJ45
  • PCB Mounting Orientation = Right Angle
  • PCB Mount Style = Surface Mount
  • Termination Method to PC Board = Solder
  • Grounding Options = Without
  • Panel Stops = With
  • Keyed = No
  • Profile = Low
  • Latch Style = Standard
  • Panel Mount Retention = With
  • Flanged = No
  • Shielded = No
  • Solder Tail Contact Plating = Tin over Nickel
  • Port Configuration = Single
  • Height (mm [in]) = 12.70 [0.500]
  • Inverted Jack Face = No
  • Preloaded = Yes
  • Contact Plating, Mating Area, Material = Gold (50)
  • Contact Base Material = Phosphor Bronze
  • Housing Material = High Temperature Nylon
Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Stock:Factory Stock:
1,088
Factory Lead Time:
8 Weeks
Minimum Order:
2176
Multiple Of:
136
Total
$3,916.80
USD
Quantity
Web Price
136
$2.25
272
$1.84
408
$1.82
544+
$1.80
