TE Connectivity | 2008106-1

Manufacturer Part #

2008106-1

2 Position 4 mm SMT 18 - 22 AWG Wire to Board LED Poke-In Receptacle

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
TE Connectivity 2008106-1 - Technical Attributes
Attributes Table
No of Positions: 2
Contact Termination: Poke - In
Style/Orientation: Receptacle
Material: Polymer
Mating Type: Push - Pull
Features & Applications
The 2008106-1 is a Receptacle Wire to Board Poke-In LED Connector with 2 Position and 4 mm Pitch.

Features:

  • Connector Type = Connector Assembly
  • Termination Method to PC Board = Through Hole
  • Mount Angle = Right Angle
  • Wire/Cable Type = Discrete Wire
  • Termination Method to Wire/Cable = Poke-in
  • Contact Current Rating, Max. (A) = 4
  • Operating Voltage (VAC) = 250
  • Operating Voltage (VDC) = 250
  • Wire/Cable Size (AWG) = 18 – 22
  • Wire/Cable Size (AWG) = 18 – 22
  • Contact Plating, Termination Area, Material = Matte Tin over Nickel
  • Contact Plating, Termination Area, Thickness (µm [μin]) = 3 [118.11]
  • Contact Type = Socket
  • Centerline (mm [in]) = 4.00 [0.157]
  • Connector Style = Receptacle
  • Number of Positions = 2
  • Number of Rows = 1
  • Operating Temperature (°C [°F]) = -40 – +105 [-40 – +221]
  • Applies To = Printed Circuit Board, Wire/Cable
  • Application Use = Wire-to-Board






Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Stock:Factory Stock:
0
Factory Lead Time:
32 Weeks
Minimum Order:
4200
Multiple Of:
4200
tariff icon
Tariff charges may apply if shipping to the United States. An estimate of tariff charges will be calculated at checkout.
Total
$2,310.00
USD
Quantity
Unit Price
4,200+
$0.55
