Manufacturer Part #
AS5147-HTSM
AS5147 Series 5 V 35 mT to 70 mT 14-Bit On-Axis Magnetic Rotary Position Sensor
| | |||||||||||
| | |||||||||||
| Mfr. Name: | ams OSRAM | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:500 per Reel Package Style:TSSOP-14 Mounting Method:Surface Mount | ||||||||||
| Date Code: | |||||||||||
ams OSRAM AS5147-HTSM - Product Specification
Shipping Information:
ECCN:
PCN Information:
To ensure necessary stability and flexibility, ams-OSRAM AG will make following changes. These changes will not impact the device performance nor reliability. - new lead frame design Notes: - New material ID (Selling part number) will be issued after implementation and release of new part chain. - Qualification samples will be available by end of May2022 and the target date for implementation is Q3 2022 (end of June). - Unless we receive your written refusal concerning this PCN within 30 days, the PCN shall be deemed accepted.
Part Status:
ams OSRAM AS5147-HTSM - Technical Attributes
| Type: | Angular |
| Output Type: | Digital |
| Supply Voltage: | 5V |
| Supply Current: | 15mA |
| Operating Temp Range: | -40°C to +150°C |
| Package Style: | TSSOP-14 |
| Mounting Method: | Surface Mount |
Available Packaging
Package Qty:
500 per Reel
Package Style:
TSSOP-14
Mounting Method:
Surface Mount
