Manufacturer Part #
MCP1755S-3302E/DB
MCP1755 Series 3.3V 300mA 100µA 0.5V Dropout LDO Regulator SOT-223-3
| | |||||||||||
| | |||||||||||
| Mfr. Name: | Microchip | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:78 per Tube Package Style:SOT-223 (TO-261-4, SC-73) Mounting Method:Surface Mount | ||||||||||
| Date Code: | 2503 | ||||||||||
Microchip MCP1755S-3302E/DB - Product Specification
Shipping Information:
ECCN:
PCN Information:
PCN Status: Final NotificationDescription of Change: Qualification of HANA as an additional assembly site for selected MCP1754xx and MCP1755xx device families available in 3L SOT-223 package using 100x87mils paddle size.Reason for Change: To improve on-time delivery performance by qualifying HANA as an additional assembly site.Change Implementation Status: In ProgressEstimated First Ship Date: July 20, 2024 (date code: 2429)
Part Status:
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=MCP1755S-3302E/DB&field4=Microchip&field18=https://p1na.futureelectronics.com/p/analog--regulators-reference--linear-regulators/mcp1755s-3302e-db-microchip-7076254
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=MCP1755S-3302E/DB&field4=Microchip&field18=https://p1na.futureelectronics.com/p/analog--regulators-reference--linear-regulators/mcp1755s-3302e-db-microchip-7076254
Microchip MCP1755S-3302E/DB - Technical Attributes
| Input Voltage-Min: | 3.6V |
| Input Voltage-Max: | 16V |
| Output Voltage Fixed: | 3.3V |
| Dropout Voltage-Max: | 0.5V |
| Output Current-Max: | 0.3A |
| Tolerance (%): | ±2% |
| Operating Temp Range: | -40°C to +125°C |
| Regulator Topology: | Fixed |
| Quiescent Current: | 68µA |
| No. of Outputs: | Single |
| Load Regulation (%): | 0.1% |
| Current - Limit: | 0.45A |
| Line Regulation (%): | 0.01% |
| Package Style: | SOT-223 (TO-261-4, SC-73) |
| Mounting Method: | Surface Mount |
Available Packaging
Package Qty:
78 per Tube
Package Style:
SOT-223 (TO-261-4, SC-73)
Mounting Method:
Surface Mount
