Manufacturer Part #

76PSB12ST

76 Series Side Actuated SPST 12 Position Through Hole DIP Switch

Mfr. Name: Grayhill
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
Technical Attributes
Attributes Table
Type: Dip
No of Positions: 12
Circuitry: SPST
Actuator Style: Side Actuated
Termination Style: Straight Thru Hole
Sealed Option: Sealed
Contact Resistance: 30mΩ
Voltage Rating: 30V
Current Rating: 150mA
Insulation Resistance: 5000MΩ
Terminal Pitch: 2.5mm
Operating Temp Range: -40°C to +85°C
Mounting Method: Through Hole
Pricing Section
Stock:
0
Minimum Order:
104
Multiple Of:
8
On Order:
0
Factory Stock:Factory Stock:
0
Factory Lead Time:
N/A
Total
$176.80
USD
Quantity
Web Price
1
$2.13
25
$1.80
75
$1.70
150
$1.64
400+
$1.56
