Manufacturer Part #

UB25KKW015F-FF

UB Series DPDT On-Momentary Square Green Illuminate Solder Lug Pushbutton Switch

UB25KKW015F-FF Datasheet UB25KKW015F-FF Documentation 3D Drawings
ECAD Model: Download the CAD models for this product. Learn more about SnapMagic.
Mfr. Name:	NKK Switches
Standard Pkg:	Product Variant Information section Available Packaging Std. Mfr. Pkg Std. Mfr. PkgSelected Variant Qty: 1+ / Unit Price: $11.75 / Stock: 0 Qty: 1+$11.75 Stock: 0 Package Qty: 1 per Std. Mfr. Pkg Mounting Method: Panel Mount
Date Code:

NKK Switches UB25KKW015F-FF - Technical Attributes

Contact Current-Max:	5A
Switch Operation:	On-Mom
Circuitry:	DPDT
Illumination Color:	Green
Actuator Style:	Square
Termination Style:	Solder Lug
Mounting Method:	Panel Mount

Features & Applications

The UB25KKW015F-FF-RO is a DPDT On-Momentary Square Green Illuminate Solder Lug Pushbutton Switch. This switch having combination of PCB mountability and short body allows use in compact applications.

Snap-acting contact mechanism provides sensitive actuation with audible feedback; quick-make, quick-break characteristic limits arcing and prolongs electrical life. Latchdown mechanism, independent of switching mechanism, gives visible and tactile indication of circuit status. Terminals are epoxy sealed to lock out flux, solvents, and other contaminants.

Specifications:

Power Level: 5 A @ 125/250 V AC or 5 A @ 30 V DC
Logic Level: 0.4 VA maximum @ 28 V AC/DC maximum
Mechanical Life:
- 1,000,000 operations minimum for momentary
- 200,000 operations minimum for alternate action
Electrical Life:
- 10,000 operations minimum for silver
- 100,000 operations minimum for silver with resistive load of 3 A @ 125 V AC
- 200,000 operations minimum for gold
Operating Temp Range: –25°C through +50°C (–13°F through +122°F)
