Manufacturer Part #
2-1761603-1
AMP-LATCH 6 Position 2.54 mm Dual Row Through-Hole Straight Pin Header
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:50 per Mounting Method:Through Hole | ||||||||||
| Date Code: | 1821 | ||||||||||
Product Specification Section
Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
Technical Attributes
Attributes Table
| No of Positions: | 6 |
| Pitch: | 2.54 mm |
| Style/Orientation: | Straight Header/Plug |
| Termination: | Solder |
| Operating Temp Range: | -65°C to +105°C |
| Voltage Rating: | 250V |
| Current Rating: | 1A |
| Contact Plating: | Gold |
| Material: | Polybutylene Terephthalate |
| No of Rows: | 2 |
| Gender: | Male |
| Type: | Pin Headers |
| Mating Type: | Push - Pull |
| Color: | Blue |
| Insulation Resistance: | 5000MΩ |
| Mounting Method: | Through Hole |
Features & Applications
The 2-1761603-1 is a AMP-LATCH 6 Position Through-Hole Dual Row Straight Pin Header .
Features:
- Connector
- LOw Profile
- AMP Latch Product line
- Number of Positions 6
- Number of Rows are 2
- Pin Header
- Centreline is 4.20 mm [0.165 in]
- Thermoplastic-GF Housing Material
Pricing Section
Global Stock:
2,550
Germany (Online Only):
2,550
On Order:
0
Factory Lead Time:
11 Weeks
Quantity
Web Price
50
$1.56
150
$1.34
250
$1.32
1,000
$1.27
1,500+
$1.25
Product Variant Information section
Available Packaging
Package Qty:
50 per
Mounting Method:
Through Hole
