Manufacturer Part #
2-640502-2
9 Position 0.1649 inch Red Miniature Rectangular Vertical Wire to Board Header
|
|
|||||||||||
|
|
|||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: |
Product Variant Information section
Available PackagingPackage Qty:200 per Bag Mounting Method:Through Hole |
||||||||||
| Date Code: | |||||||||||
TE Connectivity 2-640502-2 - Product Specification
Shipping Information:
HTS Code:
ECCN:
PCN Information:
Part Status:
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=2-640502-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-pcb--header-plug-board-mount/2-640502-2-te-connectivity-2897254
-
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=2-640502-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--connectors-pcb--header-plug-board-mount/2-640502-2-te-connectivity-2897254
TE Connectivity 2-640502-2 - Technical Attributes
| No of Positions: | 12 |
| Pitch: | 4.19 mm |
| Style/Orientation: | Vertical Header/Plug |
| Termination: | Solder |
| Type: | Wire to Board |
| Mounting Method: | Through Hole |
Features & Applications
The AMP Soft Shell Pin and Socket connectors provide a highly reliable and economic means of grouping multiple-lead connections in today's computer, computer/peripheral equipment, business machines, entertainment centers, appliances and other sophisticated commercial equipment.
Product Features:
- Product Type = Connector
- Connector Type = Header
- PCB Mount Retention = Without
- Termination Method to PC Board = Through Hole - Solder
- PCB Mounting Orientation = Vertical
- PCB Mount Alignment = Without
- Shrouded = Yes
- Shape = Rectangular
- Mating Retention Type = Positive Lock
- Contact - Rated Current (A) = 9
- Hot Pluggable = No
- Operating Voltage Reference = AC
- Operating Voltage (VAC) = 250
- Tail Length (mm [in]) = 3.81 [0.149]
- Tail Orientation = In-line
- Profile Height (Y-Axis) (mm [in]) = 13.46 [0.530]
- Number of Positions = 12
- Number of Rows = 4
- Number of Columns = 3
- Length (X-Axis) (mm [in]) = 19.94 [0.785]
- Width (Z-Axis) (mm [in]) = 19.94 [0.785]
- Header Type = Shrouded
- Centerline (mm [in]) = 4.19 [0.1649]
View the Complete Family of Rectangular Vertical Wire to Board Headers
Available Packaging
Package Qty:
200 per Bag
Mounting Method:
Through Hole
