TE Connectivity | 5414363-3

Manufacturer Part #

5414363-3

Coaxial Cable Terminate Straight Quick Connect/Disconnect SMB RF Connector Plug

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
TE Connectivity 5414363-3 - Technical Attributes
Attributes Table
Mounting Method: Quick Connect
Features & Applications

The 5414363-3 is a SMB Connectors are available in commercial and high rel versions. They are ideally suited for circuit miniaturization and are offered in a wide range of configurations including plugs, right-angle plugs,jacks, bulkhead jacks and adapters, as well as printed circuit board and solder jacks.

Features:

  • Product Type = Connector - RF
  • Gender = Plug
  • Connector Series = Standard
  • Body Style = Right Angle
  • Grade = Consumer
  • Body Material = Zinc
  • PCB Mounting Orientation = Vertical
  • Dielectric Material = TEFLON
  • Connector Impedance (?) = 50
  • Coupler Style = Quick Connect/Disconnect
  • Body Plating = Nickel Over Copper
  • Applies To = Coaxial Cable
  • Outer Contact Plating = Gold over Nickel
  • Center Contact Plating = Gold over Nickel



Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Stock:Factory Stock:
0
Factory Lead Time:
12 Weeks
Minimum Order:
2000
Multiple Of:
2000
Total
$7,720.00
USD
Quantity
Unit Price
2,000+
$3.86
Product Variant Information section
Related Products
413985-3
