Manufacturer Part #
3-520340-2
Ultra Fast 16-14 AWG Straight Fully Insulated Receptacle Assembly
|
|
|||||||||||
|
|
|||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: |
Product Variant Information section
Available PackagingPackage Qty:11000 per Reel |
||||||||||
| Date Code: | |||||||||||
TE Connectivity 3-520340-2 - Product Specification
Shipping Information:
HTS Code:
ECCN:
PCN Information:
Part Status:
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=3-520340-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--crimp-terminals/3-520340-2-te-connectivity-7102171
-
https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=3-520340-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/interconnect--crimp-terminals/3-520340-2-te-connectivity-7102171
TE Connectivity 3-520340-2 - Technical Attributes
| Size: | Tab 0.187" x 0.032" |
| Style: | Fully Insulated |
| Type: | Receptacle |
| Wire Gauge: | AWG 16-14 |
Features & Applications
The Ultra Fast Series is a 16-14 AWG Straight Fully Insulated Receptacle Assembly
The Ultra-Fast Fully Insulated FASTON Receptacle and Tab offers the advantage of a completely protected terminal and a wire crimp with comparable electromechanical performance to open barrel “F” crimp FASTON Terminals.
Features:
- Terminal Type = Receptacle
- Proprietary Name = Ultra-Fast
- Receptacle Style = Straight
- Mating Area Interface Dimensions (mm [in]) = 4.75 x 0.81 [.187 x .032]
- Material = Brass
- Insulation Diameter (mm [in]) = 4.69 [.185] Max.
- Insulation Support = Non-Insulation Support
- Finish = Tin
Available Packaging
Package Qty:
11000 per Reel
