MC9S08GT16ACFDE
HCS08 Series 16 KB Flash 2 KB RAM 40 MHz 8-Bit Microcontroller - QFN-48EP
| | |||||||||||
| | |||||||||||
| Mfr. Name: | NXP | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:1300 per Tray Package Style:QFN-48 Mounting Method:Surface Mount | ||||||||||
| Date Code: | |||||||||||
Product Specification Section
NXP MC9S08GT16ACFDE - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=MC9S08GT16ACFDE&field4=NXP&field18=https://p1na.futureelectronics.com/en/p/1715689
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=MC9S08GT16ACFDE&field4=NXP&field18=https://p1na.futureelectronics.com/en/p/1715689
NXP MC9S08GT16ACFDE - Technical Attributes
Attributes Table
| Family Name: | HCS08 |
| Core Processor: | S08 |
| Program Memory Type: | Flash |
| Flash Size (Bytes): | 16kB |
| RAM Size: | 2kB |
| Speed: | 20MHz |
| No of I/O Lines: | 39 |
| InterfaceType / Connectivity: | I2C/SCI/SPI |
| Peripherals: | I2C/On-Chip-ADC/PWM/SCI/SPI/Watchdog |
| Number Of Timers: | 1 |
| Supply Voltage: | 1.8V to 3.6V |
| Operating Temperature: | -40°C to +125°C |
| On-Chip ADC: | 8-chx10-bit |
| Watchdog Timers: | 1 |
| Package Style: | QFN-48 |
| Mounting Method: | Surface Mount |
Features & Applications
The MC9S08GT family are members of the low-cost, high-performance HCS08 general pouprpose 8-bit microcontrollers. All MCUs in the family use the enhanced HCS08 core and are available with a variety of modules, memory sizes, memory types and package types.
Additionaly, the MC9S08GT16A and MC9S08GT8A series of microcontrollers further extend the GT family to smaller memory sizes, while maintaining higher end functionality often associated with more expensive parts. MC9S08GT16A doubles the RAM of its predecessor.
Features:
- 20-MHz HCS08 CPU
- HC08 instruction set with added BGND instruction
- Support for up to 32 interrupt/reset sources
- Three very low power stop modes
- Reduced power wait mode
- Very low power real time interrupt for use in run, wait, and stop
- Optional watchdog computer operating properly (COP) reset
- Low-voltage detection with reset or interrupt
- Illegal opcode detection with reset
- Illegal address detection with reset
- FLASH block protect and security
Applications:
- Handheld instruments
- Utility meters
- Security Systems
- Portable consumer devices
