Manufacturer Part #
7140DG
TO-220 Package 20.80 C/W Thermal Resistance Copper Hat Slide On Heat Sink
| | |||||||||||
| | |||||||||||
| Mfr. Name: | Boyd | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:1250 per Bag | ||||||||||
| Date Code: | |||||||||||
Boyd 7140DG - Product Specification
Shipping Information:
ECCN:
PCN Information:
Part Status:
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=7140DG&field4=Boyd&field18=https://p1na.futureelectronics.com/p/3830254
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=7140DG&field4=Boyd&field18=https://p1na.futureelectronics.com/p/3830254
Boyd 7140DG - Technical Attributes
| Thermal Resistance: | 20.8°C/W |
| Material: | Matte Tin Finish |
| Dimension: | H 17.78mm x L 9.52mm x W 22.86mm |
Features & Applications
Boyd is the world’s largest thermal management provider. With their world-class production facilities and over 40 years of experience in the industry, Aavid Thermalloy has the know-how and ability to provide a solution to the most demanding thermal challenges. Aavid Thermalloy continues to be an innovator in thermal management technologies and a leader in heat sink manufacturing.
The 7140DG is a TO-220 package heat sink with a thermal resistance of 20.80 C/W. The 7140DG is a copper hat section slide on heat sink. The 7140DG is black anodized.
Available Packaging
Package Qty:
1250 per Bag
