Murata Power Solutions | NDY1205C

The NDY1205C series is a range of low profile DC/DC converters offering a single regulated output over a 2:1 input voltage range. All parts deliver 3W output power up to 85ºC without heatsinking, except the 4.5 V to 9 V input voltage range which should be derated to 2 W at the lower input voltage. A fly back oscillator design with isolated feedback is used to give regulation over the full operating range of 25% to 100% of full load. It is strongly recommended that external capacitors be used on input and output to guarantee performance over full load and input voltage range.

Features:

• UL 60950 recognized
• RoHS compliant
• Industry standard footprint
• Efficiency to 82%
• Power density 0.90 W/cm3
• 2:1 wide input range
• Single isolated output
• Short circuit protection
• Low profi le 24 pin case
• UL 94 V-0 package material
• Operating temperature range -40ºC to 85ºC
• No heatsink required
• Footprint 4.73 cm2
• 5 V, 12 V, 24 V & 48 V input
• 3.3 V, 5 V, 9 V, 12 V & 15 V output
• Internal SMD construction
• Fully encapsulated
