Murata Power Solutions | NMV0512SC

The NMV0512SC is a part of NMV series DC/DC power supply. It has an operating temperature ranging from -40°C to +85°C and is available in SIP-5 package.

The NMV series of industrial temperature range DC/DC converters are the standard buliding blocks for on-board distributed power systems. They are ideally suited for providing local supplies on control system boards with the added benefit of 3 kVDC galvanic isolation to reduce switching noise. Available in SIP and DIP with dual and single output pinout. All of the rated power may be drawn from a single pin provided the total load does not exceed 1 watt.

Features:

• Efficiency to 79%
• Power density up to 0.85W/cm3
• Wide temperature performance at full 1 Watt load, –40°C to 85°C
• Single or dual output
• UL 94V-0 package material
• No heatsink required
• Footprint from 1.17cm2
• Industry standard pinout
• Power sharing on dual output
• 3 kVDC isolation (1 minute)
• 5 V, 12 V, & 15 V input
• 5 V, 9 V, 12 V and 15 V output
• Internal SMD construction
• Fully encapsulated with toroidal magnetics
• No external components required
• MTTF up to 4.2 million hours
• No electrolytic or tantalum capacitors
