Manufacturer Part #
1-480277-0
MATE-N-LOK 9 Position Triple Row 5.13 mm Pitch Receptacle Housing Connector
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:300 per Box | ||||||||||
| Date Code: | |||||||||||
Product Specification Section
Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
File
Date
Assembly Site Change
08/14/2019 Details and Download
Description of Changes Manufacturing location change. Part Numbers listed in this notice will be transferred from TE Qingdao plant and Japan to TE Qingdao plant only. Reason for Changes: Dear Customer, as a result of our continuous strive for improving our processes, we hereby inform you about following parts will have only single source at TE Qingdao in future.
Part Status:
Active
Active
Technical Attributes
Attributes Table
| Type: | Housing |
| No of Positions: | 9 |
| Pitch: | 5.13 mm |
| Style/Orientation: | Receptacle |
| Termination: | Crimp |
Features & Applications
The 1-480277-0 is a Part of MATE-N-LOK Series with 9 Position 5.13 mm Pitch Triple Row Receptacle Housing Connector.
Features:
- Connector Type = Housing
- Termination Method to Wire/Cable = Crimp
- Wire/Cable Type = Discrete Wire
- Industry Application = ATM Machines, Inkjet, MFP/LBP, Projector, Scanner
- Mating Retention Type = Positive Lock
- Contact - Rated Current (A) = 13
- Operating Voltage (VAC) = 250
- Row-to-Row Spacing in mm = 6.09
- Contact Diameter in mm = 2.13
- Connector Style = Receptacle
- Housing Material = Nylon
- Housing Color = Natural
- Contact Type = Pin
- Applies To = Wire/Cable
Mating Products:
- 1-480274-0
- 350642-1
- 350577-1
- 1-171197-0
View the Series of MATE-N-LOK Connectors
Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Lead Time:
12 Weeks
Quantity
Web Price
300
$1.02
600
$0.84
900
$0.825
1,200+
$0.82
Product Variant Information section
Available Packaging
Package Qty:
300 per Box
