TE Connectivity | 102203-1

The 102203-1 is a AMPMODU 4 Position Through-Hole Single Row Right Angle .100 Inch Shrouded Header

Product Features:

• Product Type = Connector
• Mount Angle = Right Angle
• PCB Mount Retention = Without
• Surface Mount Compatible = No
• Board Standoff = With
• Mounting Ears = Without
• Mating Connector Lock = Without
• Housing Style = 4-Sided
• Post Size (mm [in]) = 0.64 [.025]
• Profile = Standard
• Mating Post Length (mm [in]) = 6.10 [0.240]
• Panel Mount Retention = Without
• Current Rating (A) = 3
• Insulation Resistance (M?) = 5,000
• Dielectric Withstanding Voltage (V) = 750
• Termination Post Length (mm [in]) = 2.79 [0.110]
• Solder Tail Contact Plating = Tin-Lead over Nickel
• Header Type = Shrouded
• Number of Positions = 4
• Centerline (mm [in]) = 2.54 [0.100]
• Row-to-Row Spacing (mm [in]) = 2.54 [0.100]
• Number of Rows = 1
• Selectively Loaded = No
• Mount Type = Printed Circuit Board
• Contact Plating, Mating Area, Material = Gold (15)
• Contact Shape = Square
• Contact Base Material = Phosphor Bronze
• Housing Material = Thermoplastic - GF
• Housing Color = Black
• UL Flammability Rating = UL 94V-0

Mating Product:

• 487769-2
