TE Connectivity | 104071-3

Manufacturer Part #

104071-3

AMPMODU 15 Position 1.27 mm Through-Hole Single Row Straight Shrouded Header

ECAD Model:
Mfr. Name: TE Connectivity
Standard Pkg:
Product Variant Information section
Date Code:
Product Specification Section
TE Connectivity 104071-3 - Technical Attributes
Attributes Table
No of Positions: 15
Pitch: 1.27 mm
Style/Orientation: Straight Header/Plug
Termination: Solder
Type: Shrouded Header
Mounting Method: Through Hole
Features & Applications

The 104071-3 is a AMPMODU 15 Position Through-Hole Single Row Straight .050 x .100 Shrouded Header

Product Features:

  • Connector Type = Header
  • Shrouded = Yes
  • Mount Angle = Vertical
  • PCB Mount Style = Through Hole
  • PCB Mount Retention = Without
  • Voltage (VAC) = 30
  • Insulation Resistance (M?) = 5,000
  • Dielectric Withstanding Voltage (V) = 500
  • Termination Post Length (mm [in]) = 2.54 [0.100]
  • Solder Tail Contact Plating = Tin-Lead
  • Number of Positions = 15
  • Number of Rows = Single
  • Contact Base Material = Phosphor Bronze
  • Contact Plating, Mating Area, Material = Gold (30)
  • Connector Style = Plug
  • Housing Material = Thermoplastic - GF
  • UL Flammability Rating = UL 94V-0
  • Housing Color = Black

Mating Products:

  • 5-104192-4
  • 104192-4
  • 1-487545-2
  • 1-487544-2

View the Complete AMPMODU Series of Header Plug

Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Stock:Factory Stock:
0
Factory Lead Time:
18 Weeks
Minimum Order:
1512
Multiple Of:
1512
tariff icon
Tariff charges may apply if shipping to the United States. An estimate of tariff charges will be calculated at checkout.
Total
$4,626.72
USD
Quantity
Unit Price
1,512+
$3.06
