Image for illustration purposes only,
refer to technical specifications

Manufacturer Part #

LPC2478FET208,551

LPC24xx Series 512 kB Flash 98 kB RAM 72 MHz 16/32-Bit Microcontroller-TFBGA-208

LPC2478FET208,551 Datasheet LPC2478FET208,551 Documentation User manual Selection Guide Leaflet LPC Discovery
ECAD Model: Convert this file for your ECAD tool by downloading the free Library Loader. Learn more about ECAD model.
Mfr. Name:	NXP
Standard Pkg:	Product Variant Information section Available Packaging Package Qty: 126 per Tray Package Style: TFBGA-208 Mounting Method: Surface Mount
Date Code:	2426

NXP LPC2478FET208,551 - Technical Attributes

Family Name:	LPC24xx
Core Processor:	ARM7
Program Memory Type:	Flash
Flash Size (Bytes):	512kB
RAM Size:	98kB
Speed:	72MHz
No of I/O Lines:	160
InterfaceType / Connectivity:	CAN/IrDA/I2C/I2S/LCD Graphic Controller/SPI/SSP/UART/USB
Peripherals:	CAN/IrDA/I2C/I2S/On-Chip-ADC/PWM/SPI/SSP/UART/USB/Watchdog
Number Of Timers:	4
Supply Voltage:	3V to 3.6V
Operating Temperature:	-40°C to +85°C
On-Chip ADC:	8-chx10-bit
Watchdog Timers:	1
Package Style:	TFBGA-208
Mounting Method:	Surface Mount

Expand List

Collapse List

Features & Applications

The LPC2478FET208,551 is a Part of LPC2478 Series 98 kB RAM 72 MHz 512 kB flash memory Single-Chip 16/32-Bit Microcontroller.Operating temperature ranges between -40 to 85°C and is available in TFBGA-208 Package.

Features and benefits:

ARM7TDMI-S processor, running at up to 72 MHz.
512 kB on-chip flash program memory with In-System Programming (ISP) and In-Application Programming (IAP) capabilities
98 kB on-chip SRAM includes:
- 64 kB of SRAM on the ARM local bus for high performance CPU access.
- 16 kB SRAM for Ethernet interface. Can also be used as general purpose SRAM.
- 16 kB SRAM for general purpose DMA use also accessible by the USB.
- 2 kB SRAM data storage powered from the Real-Time Clock (RTC) power domain.
LCD controller, supporting both Super-Twisted Nematic (STN) and Thin-Film Transistors (TFT) displays.
no contention.
EMC provides support for asynchronous static memory devices such as RAM, ROM and flash, as well as dynamic memories such as single data rate SDRAM.
Advanced Vectored Interrupt Controller (VIC), supporting up to 32 vectored interrupts.
General Purpose DMA (GPDMA) controller on AHB that can be used with the SSP, I²S-bus, and SD/MMC interface as well as for memory-to-memory transfers
EMC provides support for asynchronous static memory devices such as RAM, ROM and flash, as well as dynamic memories such as single data rate SDRAM.
Advanced Vectored Interrupt Controller (VIC), supporting up to 32 vectored interrupts.
General Purpose DMA (GPDMA) controller on AHB that can be used with the SSP, I²S-bus, and SD/MMC interface as well as for memory-to-memory transfers
Two indep
