Manufacturer Part #
179228-2
AMP CT 2 Position Single Row Free Hanging Receptacle Wire to Board Housing
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:108000 per Box | ||||||||||
| Date Code: | |||||||||||
Product Specification Section
TE Connectivity 179228-2 - Product Specification
Shipping Information:
Item cannot ship to certain countries. See List
Item cannot ship to following countries:
ECCN:
EAR99
PCN Information:
N/A
File
Date
Part Status:
Active
Active
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=179228-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/2679538
- https://futureelec.wufoo.com/forms/?formname=r8bzou01ws8brs&field12=NA&field16=en&field2=179228-2&field4=TE Connectivity&field18=https://p1na.futureelectronics.com/p/2679538
TE Connectivity 179228-2 - Technical Attributes
Attributes Table
| No of Positions: | 2 |
| Pitch: | 2 mm |
| Style/Orientation: | Free Hanging Socket/Receptacle |
| Termination: | Crimp |
| Operating Temp Range: | -30°C to +105°C |
| Voltage Rating: | 125V |
| Current Rating: | 4A |
| Contact Plating: | Tin |
| Material: | Thermoplastic |
| No of Rows: | 1 |
| Gender: | Female |
| Type: | Wire to Board |
| Color: | Natural |
| Insulation Resistance: | 1000MΩ |
Features & Applications
The 179228-2 is a 2 Position Single Row 0.079 inch Free Hanging Receptacle Wire to Board Housing. It has an operating temperature range of -30 to +105 [-22 – +221] = (°C [°F]).
Features:
- Product Type = Connector
- Connector Type = Housing
- Termination Method to Wire/Cable = Crimp
- Sealed = No
- Contact - Rated Current (A) = 4
- Operating Voltage Reference = AC/DC, AC, DC
- Wire/Cable Size (AWG) = 22 – 30
- Number of Positions = 2
- Number of Rows = 1
- Centerline (mm [in]) = 2.00 [0.079]
- Mating Retention = Without
- Contact Type = Socket
- Connector Style = Receptacle
- Housing Color = Natural
- UL Flammability Rating = UL 94V-0
Applications:
- Wire-to-Board
- Wire-to-Board / Wire-to-Wire
- Wire-to-Wire
- Contact Transmits
- Pick and Place Cover
View the available 179228 Series of Housing Connectors
Pricing Section
Global Stock:
0
USA:
0
On Order:
0
Factory Lead Time:
7 Weeks
Quantity
Unit Price
108,000+
$0.0846
Product Variant Information section
Available Packaging
Package Qty:
108000 per Box
