TE Connectivity | 643428-1

The 643428-1 is a 5.0 mm Power Key Connectors are for power circuits of home appliances, especially targeting gas appliances. The connector features four kinds of keying per housing. Only color-coding of housings limited the efficiency of blind mating where you could not see connectors. However, the new keying mechanism not only improves assembly efficiency but also helps prevent mismating.

Features:

• Product Typ:
• Product Type = Connector
• Product Line = Universal MATE-N-LOK
• Connector Type = Header
• Color = White
• PCB Mount Alignment = With
• Mount Angle = Vertical
• Mechanical Attachment:
• Mating Retention Type = Positive Lock
• Electrical Characteristics:
• High Current = No
• Current Rating (A) = 19
• Voltage (VAC) = 600
• Termination Related:
• Termination Method = Solder
• Termination Post Length (mm [in]) = 4.45 [0.175]
• Body Related Features:
• Row-to-Row Spacing (mm [in]) = 6.35 [0.250]
• Centerline (mm [in]) = 6.35 [0.250]
• Number of Positions = 12
• Mating Retention = With
